Condair DL Hybrid Humidifier

Condair DL Hybrid Humidifier for AHUs

Nehmen Sie Kontakt mit uns auf

Condair DL

Hybrid Humidifiers

The Condair DL is the next generation of the Condair Dual2—the successful system for adiabatic air humidification. Its hygienic credentials have proven successful in practice and were verified and certified by independent organisations with public responsibility.

Condair DL hybrid humidifier

Top of page Features Product Details Downloads FAQs References

Two adiabatic methods intelligently combined!

The adiabatic humidifier Condair DL relies exclusively on the advantages of the two types of humidification, atomization and evaporation. This provides a sustainable solution to central problems that can arise when these techniques are used in isolation.

HygienePlus® method

The HygienePlus® process prevents the formation and spread of germs and pathogens in air conditioning systems and humidifiers. Since even drinking water is not germ-free, biofilms and microorganisms can otherwise form there. Through targeted hygiene measures, the process ensures clean, healthy air at all times.

Extremely short length

Low-pressure systems generally get by with a significantly shallower design depth than high-pressure humidifiers. Due to the arrangement of the evaporator ceramics so that they cover the full area, and as a result of the spray cone of the molecular diffuser nozzles, the entire overall depth of the Condair DL can be reduced to up to 600 mm.

System structure Hybrid humidifier

Professional planning is the basis for functional quality and energy efficiency. We are happy to assist you in the planning phase.

System structure Hybrid humidifier

Fine filter

System structure Hybrid humidifier

Pipe disconnector

System structure Hybrid humidifier

Softener

System structure Hybrid humidifier

Reverse osmosis

System structure Hybrid humidifier

Control unit

System structure Hybrid humidifier

Hygieneplus®

System structure Hybrid humidifier

Atomizer unit

System structure Hybrid humidifier

Evaporator unit

Downloads

Frequently asked questions

How is water quality ensured during operation of the Condair DL?

What control options does the Condair DL offer?

What types of applications is the Condair DL best suited for?

Discover Condair in action

Projects and references

ADAC Center, Munich

In March 2012, ADAC™s new headquarters officially opened for business after six years of construction. Since December 2011, the office has been home to some 2,400 employees in over 100 professions, who were previously spread out across seven different locations. Bringing them all together in one place will encourage innovative ways of working, improve the speed of business processes, and simplify member services.

ADAC Center, Germany

Elbphilharmonie, Hamburg - Germany

In January 2017, the Elbphilharmonie (or Elbe Philharmonic Hall) was officially opened after about ten years of construction work. Its unique glass facade, which plays on visual associations with sails and ocean waves, has already established itself as a new landmark of the Hanseatic City of Hamburg. Inside the Elbphilharmonie™s main concert hall, specially-designed and individually-carved wall and ceiling elements provide incredibly precise sound diffusion and perfect acoustics.

The main hall has 2,100 seats in total, and each seat is individually supplied with fresh air. Condair DL hybrid humidifiers ensure comfort for visitors and optimal acoustic conditions for the orchestra.

Elbphilharmonie, Hamburg - Germany

BMW Welt

BMW World is located in an important location in Munich between the BMW four-cylinder and the Olympic Park. It was opened in October 2007 and has since provided space for exhibitions, the delivery of new vehicles and events.The open design was developed by the architects Himmelb(l)au and is characterized by the striking double cone at the southern tip of the building. This has a diameter of 40 meters, is around 30 meters high andmade of 680 tons of steel. Condair DL hybrid humidifiers are used to provide visitors and employees with a pleasant and hygienic room climate.

BMW Headquarters, Munich - Germany

Paul Klee Museum, Bern, Switzerland

The Kunstmuseum, Zentrum Paul Klee, is located in Bern, Switzerland, in the immediate vicinity of the Schlosshalde cemetery, where Paul Klee™s grave can also be found. The building is dominated by curved arches that blend harmoniously into the surrounding hilly landscape. It houses the comprehensive work of the Paul Klee Foundation and reflects the artist™s complexity through the division into three hills. The North Hill is dedicated to practical art education, conferences, and workshops. The Central Hill is used for collection presentation and temporary exhibitions, the South Hill for research and administration. Condair™s DL hybrid air humidifiers create an optimum indoor climate for visitors and the sensitive works of art.

Paul Klee Museum, Bern

Musée Atelier Audemars Piquet, Switzerland

The Musée Atelier Audemars Piguet invites visitors to explore the heritage of Swiss Haute Horlogerie. Combining striking architecture, living workshops, and a collection of over 300 timepieces, it offers a unique journey into the brand™s past, present, and future.

To ensure that visitors enjoy this journey in perfect comfort, Condair DL hybrid humidifiers maintain an ideal atmospheric humidity. This subtle yet essential technology protects the delicate timepieces on display while creating a pleasant environment for guests ” a perfect balance between preservation and well-being.

Audemars Piguet, Le Brassus - Switzerland

Foundation Michalski, Switzerland

An ideal work site for literature and literati &mdash that was the vision that Vera and Jan Michalski wanted to achieve with the Maison d'Écriture. It is located at the foot of the Vaud Jura Mountains, in the Bois Ditsert in Montricher, with a view of Lake Geneva and the Alps. The site was chosen for its scenic beauty and the quiet surroundings that are supposed to have a positive effect on writers' activities and inspire them to reflect. This location has a very special appeal and a unique atmosphere. Architects V. Mangeat and P. Wahlen were tasked with designing the architecture of the object. They created several buildings for the foundation's numerous activities that fit perfectly into the surrounding nature and form a kind of settlement. Individual living spaces for authors, a dining room, a recreation room, a large library for research, a room with modular space for exhibitions and an auditorium for all kinds of events promise numerous encounters and brisk cultural exchange. Condair DL hybrid humidifiers ensure comfortable atmospheric humidity.

Foundation Michalski in Montricher

Musée du Louvre, Paris

The Louvre Museum is a museum located within the Louvre Palace in the 1st arrondissement of Paris, France. It houses some of the most iconic works of Western art, including the Mona Lisa and the Venus de Milo.
With 72,735 mÂ² of rooms and galleries, it is the largest art museum in the world, ahead of the Hermitage Museum (66,842 mÂ²) in Russia and the National Museum of China (65,000 mÂ²).

Various Condair humidity control technologies (Condair DL, RS, ME, DC) help maintain the ideal indoor humidity for the preservation of the exhibits and the well-being of staff and visitors.Â

Louvre Museum France - Humidity control

Precise humidity protects millions of books at Bibliothèque Nationale de France

As one of the most recognisable and symbolically powerful architectural landmarks of contemporary Paris, the Bibliothèque nationale de France (Site François-Mitterrand) sets new standards in cultural design, monumental scale and preservation of knowledge. Condair is proud to contribute to this visionary institution with advanced hybrid humidification solutions that protect priceless collections, ensure visitor comfort and guarantee energy-efficient climate control.
Preserving millions of books, manuscripts, maps and artefacts demands rigorously stable climatic conditions. Optimal relative humidity “ crucial for preventing damage to paper, bindings and other organic materials “ is reliably maintained by Condair MK5, resistive steam humidifier.

ARoS Aarhus Art Museum, Aarhus

The Aarhus Art Museum was founded in 1859. After several relocations, an architectural competition was held with the support of Queen Margrethe II for a new building, which was won by the Danish architectural firm Schmid, Hammer, and Lassen. The cube-shaped building, with a floor area of 52 by 52 meters and a height of 42 meters, has nine floors with 17,700 square meters of exhibition space, which is primarily dedicated to contemporary art.

The building is recognizable from afar thanks to the œYour Rainbow Panorama, a circular walkway on the roof with a diameter of 52 meters that shines in all facets of the color spectrum. Hybrid humidifiers from Condair ensure comfortable room humidity and preserve the value of over 1,100 paintings, 400 sculptures, and installations.

ARoS Aaarhus Art Museum, Denmark

Rjiksmuseum, Netherlands

The Rijksmuseum is one of the world™s finest art museums with over 1.5km of galleries and artworks by Rembrandt, Vermeer and Van Gogh. The Condair DL hybrid humidifier is maintaining the ideal humidity for the preservation of paintings such as The Night Watch, The Milkmaid and The Merry Drinker.

Rijksmuseum, Amsterdam - Netherlands

Baloise Park, Basel

Baloise Park forms an area with three buildings on which the Baloise insurance group is headquartered. The complex offers 1,300 modern office workstations, of which 700 are used for Baloise employeesand the rest are rented out. The tallest building in Baloise Park is the tower in the west, which is one of the tallest buildings in Basel at 89 meters.Part of this tower houses the 5-star Superior Hotel Mövenpick comprising 264 rooms and an exquisite bar with sun terrace.Condair steam humidifiers ensure healthy room air humidity.
